自定义条目数量的底部弹框

前言

什么都不说了，先上效果图

知识点

该功能的实现主要依赖于以下两点

• 载体：DialogFragment（android.support.v4.app）
• Item：代码动态添加

以前写提示框大多是用Dialog，又或者是用PopupWindow。现在换个花样，用DialogFragment来实现。

这里用的是v4包内的DialogFragment，可以支持Android3.0之前的版本，而且android.app.DialogFragment 在API28被弃用了。

DialogFragment extends Fragment，其父类是Fragment,所以显示此布局的Activity必须是FragmentActivity的子类。

完整代码

Java

BottomPopUpDialog.java

public class BottomPopUpDialog extends DialogFragment {


    private TextView mCancel;

    private LinearLayout mContentLayout;

    private Builder mBuilder;

    private static BottomPopUpDialog getInstance(Builder builder) {
        BottomPopUpDialog dialog = new BottomPopUpDialog();
        dialog.mBuilder = builder;
        return dialog;

    }

    @Override
    public void onViewCreated(View view, @Nullable Bundle savedInstanceState) {
        super.onViewCreated(view, savedInstanceState);
        if (getDialog().getWindow() != null) {
            getDialog().getWindow().setBackgroundDrawableResource(mBuilder.mBackgroundShadowColor);
        }
    }

    @Override
    public void onCreate(@Nullable Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setStyle(DialogFragment.STYLE_NORMAL, android.R.style.Theme_Holo_Light_NoActionBar);
    }

    @Nullable
    @Override
    public View onCreateView(LayoutInflater inflater, @Nullable ViewGroup container, @Nullable Bundle savedInstanceState) {
        @SuppressLint("InflateParams") View view = inflater.inflate(R.layout.bottom_popup_dialog, null);
        initView(view);
        registerListener(view);
        setCancelable(true);
        return view;
    }


    private void initView(View view) {
        mContentLayout = view.findViewById(R.id.pop_dialog_content_layout);
        mCancel = view.findViewById(R.id.cancel);
        initItemView();
    }


    private void registerListener(View view) {

        view.setOnTouchListener(new View.OnTouchListener() {
            @SuppressLint("ClickableViewAccessibility")
            @Override
            public boolean onTouch(View v, MotionEvent event) {
                if (event.getAction() == MotionEvent.ACTION_DOWN) {
                    dismiss();
                }
                return false;
            }
        });

        mCancel.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                mBuilder.mListener.onCancleClick();
                dismiss();
            }
        });
    }


    @Override
    public void show(FragmentManager manager, String tag) {
        try {
            super.show(manager, tag);
        } catch (Exception e) {
            e.printStackTrace();
        }
    }


    private void initItemView() {
        //循环添加item
        for (int i = 0; i < mBuilder.mDataArray.length; i++) {
            final PopupDialogItem dialogItem = new PopupDialogItem(getContext());
            dialogItem.refreshData(mBuilder.mDataArray[i]);

            //最后一项隐藏分割线
            if (i == mBuilder.mDataArray.length - 1) {
                dialogItem.hideLine();
            }

            //设置字体颜色
            if (mBuilder.mColorArray.size() != 0 && mBuilder.mColorArray.get(i) != 0) {
                dialogItem.setTextColor(mBuilder.mColorArray.get(i));
            }

            //设置分割线颜色
            if (mBuilder.mLineColor != 0) {
                dialogItem.setLineColor(mBuilder.mLineColor);
            }

            //设置首项的字体大小，这里我写死为12sp
            if (i == 0) {
                dialogItem.setTextSize(12f);
            }

            mContentLayout.addView(dialogItem);

            //设置首项是否添加点击回调
            if (i == 0 && !mBuilder.firstItemClickable) {
                continue;
            }

            //设置点击回调
            dialogItem.setOnClickListener(new View.OnClickListener() {
                @Override
                public void onClick(View v) {
                    mBuilder.mListener.onDialogClick(dialogItem.getItemContent());
                    if (mBuilder.mIsCallBackDismiss) {
                        dismiss();
                    }
                }
            });
        }
    }


    public static class Builder {

        private String[] mDataArray;

        private SparseIntArray mColorArray = new SparseIntArray();

        private BottomPopDialogOnClickListener mListener;

        private int mLineColor;

        private boolean mIsCallBackDismiss = false;

        private boolean firstItemClickable = false;

        private int mBackgroundShadowColor = R.color.transparent_70;


        /**
         * 设置item数据
         */
        public Builder setDialogData(String[] dataArray) {
            mDataArray = dataArray;
            return this;
        }

        /**
         * 设置监听item监听器
         */
        public Builder setItemOnListener(BottomPopDialogOnClickListener listener) {
            mListener = listener;
            return this;
        }


        /**
         * 设置字体颜色
         *
         * @param index item的索引
         * @param color res color
         */
        public Builder setItemTextColor(int index, int color) {
            mColorArray.put(index, color);
            return this;
        }

        /**
         * 设置item分隔线颜色
         */
        public Builder setItemLineColor(int color) {
            mLineColor = color;
            return this;
        }

        /**
         * 设置是否点击回调取消dialog
         */
        public Builder setCallBackDismiss(boolean dismiss) {
            mIsCallBackDismiss = dismiss;
            return this;
        }

        /**
         * 设置首项是否可点击
         * @param firstItemClickable
         */
        public void setFirstItemClickable(boolean firstItemClickable) {
            this.firstItemClickable = firstItemClickable;
        }

        /**
         * 设置dialog背景阴影颜色
         */
        public Builder setBackgroundShadowColor(int color) {
            mBackgroundShadowColor = color;
            return this;
        }


        public BottomPopUpDialog create() {
            return BottomPopUpDialog.getInstance(this);
        }


        public BottomPopUpDialog show(FragmentManager manager, String tag) {
            BottomPopUpDialog dialog = create();
            dialog.show(manager, tag);
            return dialog;
        }


    }


    public interface BottomPopDialogOnClickListener {
        /**
         * item点击事件回调
         *
         * @param tag item字符串 用于识别item
         */
        void onDialogClick(String tag);

        /**
         * 点击取消
         */
        void onCancleClick();
    }

}

BottomPopUpDialog.java 主要是一个 Builder内部类，用于获取配置参数；

initItemView()方法，将 Builder内的mDataArray转换成PopupDialogItem显示。

setStyle()，设置显示样式。两个参数setStyle(@DialogStyle int style, @StyleRes int theme)。
style：DialogFragment提供了4种，STYLE_NORMAL, STYLE_NO_TITLE, STYLE_NO_FRAME, STYLE_NO_INPUT。

theme：自定义样式，指定该dialog样式。当该值为0时，通过style确定具体样式。

/**
 * Style for {@link #setStyle(int, int)}: a basic,
 * normal dialog.
 * 普通的dialog样式
 */
public static final int STYLE_NORMAL = 0;

/**
 * Style for {@link #setStyle(int, int)}: don't include
 * a title area.
 * 没有标题
 */
public static final int STYLE_NO_TITLE = 1;

/**
 * Style for {@link #setStyle(int, int)}: don't draw
 * any frame at all; the view hierarchy returned by {@link #onCreateView}
 * is entirely responsible for drawing the dialog.
 * 直接将onCreateView()中返回的View显示
 */
public static final int STYLE_NO_FRAME = 2;

/**
 * Style for {@link #setStyle(int, int)}: like
 * {@link #STYLE_NO_FRAME}, but also disables all input to the dialog.
 * The user can not touch it, and its window will not receive input focus.
 * 在STYLE_NO_FRAME的基础上，禁用输入
 */
public static final int STYLE_NO_INPUT = 3;


public void setStyle(@DialogStyle int style, @StyleRes int theme) {
    mStyle = style;
    if (mStyle == STYLE_NO_FRAME || mStyle == STYLE_NO_INPUT) {
        mTheme = android.R.style.Theme_Panel;
    }
    if (theme != 0) {
        mTheme = theme;
    }
}

PopupDialogItem.java

public class PopupDialogItem extends LinearLayout {


    private Context mContext;

    private TextView mContentView;

    private View mLineView;

    private String mContent;

    public PopupDialogItem(Context context) {
        super(context);
        mContext = context;
        initView();
    }

    public PopupDialogItem(Context context, AttributeSet attrs) {
        super(context, attrs);
        mContext = context;
        initView();
    }

    private void initView() {
        LayoutInflater inflater = (LayoutInflater) mContext.getSystemService(Context.LAYOUT_INFLATER_SERVICE);
        assert inflater != null;
        View view = inflater.inflate(R.layout.item_bottom_popup_dialog, this);
        mContentView = view.findViewById(R.id.popup_dialog_item);
        mLineView = view.findViewById(R.id.popup_dialog_line);
    }

    public void refreshData(String text) {
        mContentView.setText(text);
        mContent = text;
    }

    public void setLineColor(int color) {
        mLineView.setBackgroundResource(color);
    }

    public void hideLine() {
        mLineView.setVisibility(GONE);
    }

    public String getItemContent() {
        return mContent;
    }

    public void setTextColor(int textColor) {
        mContentView.setTextColor(ContextCompat.getColor(mContext, textColor));
    }

    public void setTextSize(float size) {
        mContentView.setTextSize(SP, size);
    }

}

MaxHeightScrollView.java

public class MaxHeightScrollView extends ScrollView {


    public MaxHeightScrollView(Context context) {
        super(context);

    }

    public MaxHeightScrollView(Context context, AttributeSet attrs) {
        super(context, attrs);
    }

    @Override
    protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
        Context context = getContext();
        if (null != context) {
            int screenHeight = getScreenHeight(context);
            heightMeasureSpec = MeasureSpec.makeMeasureSpec(screenHeight * 2 / 3, MeasureSpec.AT_MOST);
        }
        super.onMeasure(widthMeasureSpec, heightMeasureSpec);
    }

    /**
     * 获取屏幕高度
     */
    private int getScreenHeight(Context context) {
        DisplayMetrics metrics = context.getResources().getDisplayMetrics();
        return metrics.heightPixels;
    }


}

重写onMeasure方法，将高度设置为屏幕高度的 2 / 3。

res

bottom_popup_dialog.xml（弹框布局）

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:background="@color/transparent"
    android:gravity="bottom">

    <com.nhtzj.learn.widget.bottomsheet.MaxHeightScrollView
        android:id="@+id/sl_root"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginLeft="10dp"
        android:layout_marginRight="10dp"
        android:background="@drawable/bg_dialog"
        android:padding="2dp">

        <LinearLayout
            android:id="@+id/pop_dialog_content_layout"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:background="@drawable/bg_dialog"
            android:orientation="vertical">

        </LinearLayout>
    </com.nhtzj.learn.widget.bottomsheet.MaxHeightScrollView>

    <TextView
        android:id="@+id/cancel"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_below="@+id/sl_root"
        android:layout_marginBottom="17dp"
        android:layout_marginLeft="10dp"
        android:layout_marginRight="10dp"
        android:layout_marginTop="14dp"
        android:background="@drawable/bg_dialog"
        android:gravity="center"
        android:minHeight="55dp"
        android:padding="10dp"
        android:text="@string/cancel"
        android:textColor="@color/text_green"
        android:textSize="18sp" />


</RelativeLayout>

####item_bottom_popup_dialog.xml（item布局）

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:orientation="vertical">


    <TextView
        android:id="@+id/popup_dialog_item"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:gravity="center"
        android:minHeight="56dp"
        android:textColor="@color/text_green"
        android:textSize="18sp"/>

    <View
        android:id="@+id/popup_dialog_line"
        android:layout_width="match_parent"
        android:layout_height="0.5dp"
        android:layout_marginLeft="10dp"
        android:layout_marginRight="10dp"
        android:background="@color/line_color" />

</LinearLayout>

bg_dialog.xml （背景）

<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="rectangle">
    <corners android:radius="8dp" />
    <solid android:color="@android:color/white" />

</shape>

colors.xml

<?xml version="1.0" encoding="utf-8"?>
<resources>
	<color name="text_green">#1FC88B</color>
    <color name="text_black">#333333</color>
    <color name="text_gray">#999999</color>

    <color name="line_color">#EDEDED</color>
    <color name="transparent_70">#70000000</color>
</resources>

arrays.xml

<?xml version="1.0" encoding="utf-8"?>
<resources>
    <string-array name="array_transfer_manager">
        <item></item>
        <item>设为管理员</item>
        <item>删除</item>
    </string-array>
</resources>

使用

new BottomPopUpDialog.Builder()
             .setDialogData(getResources().getStringArray(R.array.array_transfer_manager))
             .setCallBackDismiss(true)
             .setItemTextColor(0, R.color.text_gray)
             .setItemOnListener(new BottomPopUpDialog.BottomPopDialogOnClickListener() {
                 @Override
                 public void onDialogClick(String tag) {
                     //TODO 按钮点击的回调，通过tag（按钮文本）区分
                 }

                 @Override
                 public void onCancleClick() {
		     //TODO 取消按钮点击的回调
                 }
             })
             .show(getSupportFragmentManager(), BottomPopUpDialog.class.getSimpleName());

参考

• https://blog.csdn.net/lmj623565791/article/details/37815413
